NORTON V4 SS technical highlights
ENGINE
Type: Norton 72-degree liquid-cooled V4, 1200cc. Chain-driven cams with idler gear for reduced engine height. Titanium inlet valves. Slipper clutch
Bore x Stroke: 82mm x 56.8mm
Compression Ratio: 13.6:1
Power: 200bhp + @ 12,500rpm
Torque: 130Nm @ 10,000rpm
Fuel injection: Electronic fuel-injection system. Constantly variable inlet tracts. 8-fuel injectors. Full drive-by-wire system independent of front and rear banks of cylinders for ultimate control and feel.
Euro 4: Full compliance including oil thermostat, knock sensors, secondary air injection and EVAP
ELECTRONIC EQUIPMENT:
INSTRUMENTS: Full-colour 7" display with multiple functions. Engine mode adjustability including: Road, Track and Pro-Race. Road modes include rear-view camera.
QUICKSHIFT: Full quickshift system and auto down blipper
ELECTRONIC AIDS: Multi-setting traction-control, wheelie control, launch control and cruise control. Uses six-axis Inertial Measurement Unit (IMU)
BUILT-IN DATALOGGER: Full data-logging capability including: lap times, max lean angle, max speed, max throttle, and max braking force.
ENGINE MODES: Road, Sport, Pro-Race
IGNITION: Keyless ignition system
CHASSIS:
TYPE: Polished aluminium twin tube Shotgun chassis.
ADJUSTABLE GEOMETRY: Chassis is fully-adjustable including swing arm pivot and adjustable rake angle. 23.9 degree steering head angle as standard set-up.
SINGLE-SIDED BILLET SWINGARM: 570mm long. Braced and underslung design developed in conjunction with SG5 TT race bike. Billet machined from 7020 billet aluminium.
WHEELBASE: 1430mm
DRY WEIGHT: 179kg
FRONT SUSPENSION: Ohlins NIX30 system front fork. Fully-adjustable.
REAR SUSPENSION: Ohlins TTXGP Norton bespoke fully-adjustable rear shock.
STEERING DAMPER: Ohlins damper
FORK YOKES: Billet machined top and bottom
FRONT WHEEL: Choice of carbon or forged wheels depending on spec
REAR WHEEL: Choice of carbon-fibre or forged wheels depending on spec/colour
FRONT BRAKE: Dual 330mm full-floating discs. Radially-mounted Brembo Monobloc calipers. Brembo discs, and Brembo master cylinder
REAR BRAKE: Single 330mm disc. Brembo caliper and master-cylinder
BODYWORK: Full-carbon-fibre bodywork. Available in either bare carbon-fibre, or chrome with air-brushed Union Jack on the tail unit.
LIGHTING: Full LED lighting system including super bright low beam andhigh beam, angel eye DRLs, rear lamps and indicators
FUEL TANK: MotoGP-style 18-litre fuel tank is all carbon-fibre, with Kevlar reinforcement and chemically coated internally to meet fuel resistance standards. Underside of tank forms part of upper airbox.
FOOTRESTS: Billet foot rests, billet pedals and billet sprocket cover supplied on SS model. Forged foot controls on the V4 RR.
OPTIONAL: Full titanium race system supplied with aftermarket tune, approx 8kg lighter and approx 10bhp more.
